.ads .adx .adl files for aldl logging.

[delcowizzid]

right heres a few aldl definitions to get us started thanks to mick for some of them.hopefully holden202 might unlock this thread and add some others later too .it seemed there were a few problems with certian values in the 16183082 ads file not changing (was found on the net so cant expect too much).so i made a few changes its still untested but hopefully it may have helped.or i could of duffed it all together 16233396 is still a work in progress but should work ok.


VN/VP

1277808.zip

(2.08 KiB)

VR

16183082modded.zip

(2.22 KiB)

16183082.zip

(1.91 KiB)

16176424.zip

(4.05 KiB)

VR_11_v1_03tp5_adx.zip

VR $11 TP5 ADX, Engine and Trans

(11.17 KiB)

VR_$11_v1.01.zip

(10.84 KiB)

vr_$12_v1.03.zip

(5.03 KiB)

VS

Vs V6 engine and trans 1.07-tp5.adx.zip

VS $51E TP5 ADX, Engine and Trans

(9.12 KiB)

Vs V6 engine and trans 1.07-tp5-wideband.zip

VS $51E TP5 ADX, Engine and Trans with Wideband Mod

(9.84 KiB)

vs_V6_v1.02.zip

(5.21 KiB)

VT

16233396 VT V6 $A5.zip

(4.33 KiB)

VT_$A6_v1.0.zip

VT V8

(11.28 KiB)

VX
VX S/C V6 Engine And Trans

VY


Kalmaker

KALMAKER W40 v1.00.zip

(4.62 KiB)

Kalmaker_SP3_N03_V1.00.zip

(4.37 KiB)

[Holden202]

Ok guys this is a scanner pro adx for $12 ... vr manual.

At this stage this is the first release and its not complete .... it will however show you all the sensor and flag data aswell as DTC's. When i get some more time i'll work on some other features but its a start and probably has the info you need for most logging stuff.

If anyone can break it or finds stuff not right, let me know.

EDIT 27-09-09 - added v1.03 of this adx - mainly just a few equasion fixes etc.

[antus]

Added Kalmaker SP3 N03 adx for scanner pro logging

[Holden202]

Added the second one in the VR series scanner pro adx for $11 ... vr auto.

At this stage this is the first release and its not complete .... it will however show you all the sensor and flag data aswell as DTC's. When i get some more time i'll work on some other features but its a start and probably has the info you need for most logging stuff.

for those that understand .... this one has only message 0 data, no message 4 data as its really just too slow to log both at once so im thinking i'll work on a VR $11 auto message 4 only file ......

If anyone can break it or finds stuff not right, let me know.

Edit From VL400: Have added the message 4 data stream and dashboard in V1.01. It logs both engine and transmission using the monitor macro called 'Get All Data' but as holden202 says it is much slower. You can change this by opening ScannerPro/TP5 and editing the adx. Change the monitor command to either 'Engine Data' or 'Transmission Data'.

[Holden202]

Added Kalmaker W40 - VS V6 Auto Naturally Aspirated ADX

First release, hopefully its pretty accurate .... hasn't really had any testing so fingers crossed

[Holden202]

Added VS V6 Auto Naturally Aspirated ADX

This is a newer version which has some calcs and stuff fixed so hopefully be more right ... please let me know if you find anything that doesn't seem right.
